• ANSI no.: 40-1
• Pitch p (imperial): 1/2"
• Pitch p (mm): 12,7
• Clearance width b1 (mm): 7,85
• Roller Ø d1 (mm): 7,95
• Bolt Ø d2 max. (mm): 3,96
• Inner link width b2 max. (mm): 11,150
• Fishplate height g (mm): 11,6
• Length of pin (mm): a1 max.: 16,3
• Breaking load DIN/ISO min. (N): 13900
• ISO no.: 08 A-1
• Max. width connecting link a1 (mm): 19,1
• Pin Ø d2 max. (mm): 3,96
• Pitch x inner width p x b1 (imperial): 1/2 x 5/16
• Pitch x inner width p x b1: 12,70 x 7,85
• Roll length (m): 5
• Roller Ø d1 max. (mm): 7,95
• Weight: 3.3 kg
